SEVENCRANE has successfully completed the production of a European-style single girder overhead crane system and an electric scissor lift for our customer in Peru. With a delivery schedule of 15 working days, strict configuration requirements, and CIF shipment to Callao Port, this project demonstrates our strong manufacturing capabilities, fast delivery efficiency, and technical expertise in customized lifting equipment.
The order includes:
1 set of SNHD European-style single girder overhead crane (without main girder)
1 set of SNH European-style wire rope hoist
1 set of electric self-propelled scissor lift
All equipment will be shipped by sea transportation, following the payment terms of 50% TT down payment and 50% TT before delivery.
Below is a detailed introduction to the supplied configurations and customized upgrades requested by the client.
1. Standard Product Configurations
European-Style Single Girder Overhead Crane (SNHD)
| Item | Specification |
|---|---|
| Model | SNHD |
| Working Class | A6 (FEM 3m) |
| Capacity | 2.5 tons |
| Span | 9 meters |
| Lifting Height | 6 meters |
| Control Method | Pendant + Remote Control (OM brand) |
| Power Supply | 440V, 60Hz, 3-phase |
| Quantity | 1 set |
European-Style Wire Rope Hoist (SNH)
| Item | Specification |
|---|---|
| Model | SNH |
| Working Class | A6 (FEM 3m) |
| Capacity | 2.5 tons |
| Lifting Height | 6 meters |
| Control Method | Pendant + Remote Control (OM brand) |
| Power Supply | 440V, 60Hz, 3-phase |
| Quantity | 1 set |
Electric Scissor Lift
| Item | Specification |
|---|---|
| Capacity | 320 kg |
| Max Platform Height | 7.8 meters |
| Max Working Height | 9.8 meters |
| Color | Standard |
| Quantity | 1 set |
2. Additional Customized Requirements
The customer required advanced configurations to enhance durability, safety, and operational reliability. SEVENCRANE delivered all custom features exactly as requested.
SNHD Overhead Crane – Special Configuration
-
Working Class: A6 / FEM 3m, suitable for heavy-duty industrial use
-
Power: 440V, 60Hz, 3-phase with 120V control voltage
-
Control System: Pendant + OM-brand wireless remote control
-
Motor Protection: IP55 grade for improved dust and water resistance
-
Electrical Cabinet: Full stainless-steel construction for corrosion resistance
-
Rail Adaptation: Compatible with existing 40 × 30 mm rail
-
Hoist Travel Limiter: Cross-limit system installed
-
Drive Motors: SEW brand for both trolley and crane long-travel mechanisms
SNH Wire Rope Hoist – Special Configuration
-
Designed as a spare hoist for the SNHD crane
-
Working Class: A6 / FEM 3m
-
Power: 440V, 60Hz, 3-phase with 120V control voltage
-
Control: Pendant + OM remote control
-
Motor Protection: IP55 protection rating
-
Electrical Cabinet: Stainless-steel enclosure
-
Limit System: Cross-limit travel protection
-
Travel Motor: SEW brand for smooth and reliable trolley movement
3. Reliable Manufacturing and Fast Delivery
Despite multiple customization requirements, SEVENCRANE completed production within 15 working days—a demonstration of our efficient manufacturing processes and professional engineering team.
All equipment has undergone:
-
Mechanical performance testing
-
Electrical system testing
-
Load testing
-
Remote control function verification
-
Safety limit calibration
This ensures that the entire crane and lifting system will operate safely and reliably upon arrival in Peru.
4. Commitment to Global Customers
SEVENCRANE has more than 20 years of experience in exporting cranes to international markets. For this Peru project, our team once again demonstrated our commitment to:
-
Quality manufacturing
-
Precise customization
-
On-time delivery
-
Reliable service
We look forward to supporting more customers in South America with advanced lifting solutions.
Post time: Nov-20-2025
